Fill’In are small metal spiral rods that are used to help Plastiform fluid products enter very small spaces. Among other things, they make it possible to capture the smallest details of a part or surface to be inspecte

• Thanks to its high initial Fluidity (flowable product), it can easily infiltrate into any type of part, whether small (diameter up to 0.1 mm) or medium size.
• The final impression is very flexible (hardness estimated at 20-50 Shore A), which allows it to be strongly stretched and deformed during demoulding without any problem.
• Therefore, it is recommended for taking impressions in complex internal forms (threads, grooves and internal grooves…)
• The impression is very accurate. All surface details (shape, dimension, appearance, surface condition, etc.) are reproduced in µm

• A malleable plastiform that can be applied by hand to surfaces to be inspected. Its initial consistency is similar to modelling clay.
• The final impression is Semi-Soft (hardness 70 Shore A) and has a low deformation capacity. It is a very versatile product and highly compatible with the Double Blade Cutter.
• This plastiform replica accepts a maximum Extraction Stress of 5%. Thus, this product should be used on uncomplicated shapes and partial impressions. It is recommended for creating simple external shape impressions (threads, grooves, grooves, etc.) on medium to large-sized parts.

The MD-3P is a 3 components resin (liquid resin, liquid hardener, powder) polymerizing after mixing.

The initial consistency can be Fluid or slightly Pasty depending on the mixing ratio. The final impression is that it is extremely rigid and does not accept any removal constraints. The MD-3P must be used on very simple forms and non-porous surfaces. Polymerization starts when the hardener is mixed with the other components. The reaction causes light heating, and the compound hardens in 10 to 60 minutes (depending on the mixing ratio). The impression accuracy is better than 1µm.

The MD-3P is suitable for the following applications :

• Creation of custom-made Checking Gauges

It can also be used for :

• Impression of External Simple Forms
• Roughness Control

Curing Time: 10 to 60 minutes

Removal Constraint : 0 %

Elongation to Failure : 0 %

Re-FORM is a thermoplastic resin that allows parts to be held or stiffened, or to protect them against clamping. By heating it to over 60°C, it becomes transparent, molded and malleable. You can therefore model it by hand to make it a shape that can be adapted to your needs. Once dry, it becomes extremely rigid, which allows it to protect or reinforce a part. Why use a thermoplastic resin? Thermoplastic resins are extremely hard and resistant materials in their solid state, but can be shaped manually when they reach a certain temperature. They can be very practical during the different machining processes and that’s why they are used! The Re-FORM, is a product from the Plastiform range specially dedicated to the protection or reinforcement of parts. During machining, most fragile or small parts are subjected to vibrations or embrittlement. Thermoplastic resins make it easy to solve this problem. When the Re-FORM is placed inside a hollow part or as an external reinforcement of a fragile part, it makes it more resistant to the machining operations you will have to perform.

Nozzles are small plastic parts that allow the mixing of two-component Plastiform in cartridges. They have been specially designed for mixing cartridge products. The injector mixes the two components with a 1:1 ratio, making them perfectly homogeneous at the outlet. The injector fits all our cartridges and its length (8.2cm) allows you to easily..
